STC-3008 Temperature Thermostat Controller Dual LED NTC Probe 12/24V 110-220V

STC-3008 Temperature Thermostat Controller Dual LED NTC Probe 12/24V 110-220V

1,250.00৳

  • Description
  • Additional information

Description

Product details of STC-3008 Temperature Thermostat Controller Dual LED NTC Probe 12/24V 110-220V-Black

  • Automatic conversion of cooling and heating mode
  • The mode of control of the difference in the return; Temperature display resolution 0.1
  • The temperature controller has high accuracy, high sensitivity, high stability.
  • Support for temperature correction and support for power loss (Power failure options are still valid
  • Application range like home temperature control, farm, various cold storage, greenhouse, aquarium, etc.

Display Type: Digital

Style: stationary

Temperature sensor: NTC 10 K

Length: 1.0 m

Temperature measurement range: -55 ° C ~ 120 ° C

Resolution: 0.1 ° C

Accuracy: ± 1 ° C

Power supply: 110-220VAC VAC, 50/60 Hz, operating on DC 12 V, 24 V DC (please select the power source when ordering)

Power Consumption: <3W

Storage temperature: -30 ° C ~ 75 ° C

Relative humidity: 20% ~ 85% (non-condensing)

Relay contact Capacity: two 10A / 240V AC cooling relays; Heat 10A / 240VAC

Tips: If you need an additional temperature sensor. Click here to see ( Temperature Sensor )

Package:

1X Temperature Controller

2X waterproof temperature sensor

Set start temperature:
Press the “up” button once to display the starting temperature. Long pressing the up button for about 3 seconds, the desired temperature can be set with the up and down keys.
Set the stop temperature:
Press the button once to display the stop temperature. Long press the button for about 3 seconds, and the number of stop lights flashes. The required temperature can be set with the up and down keys.
Press the “Up 1” button and the “Up 2” button at the same time on s Outing mode
CodeFunctionPreset rangeDefault
P0Compressor 1 time delay

0-60 min

0 min

P1 Compressor 2 Delay Time

0-60 min

Min

P2Heat alert and price / performance ratio

55-120 ° C

120 ° C

P3Low temperature alarm

55-120 ° C

-55 ° C

How to restore factory settings
Press the “down 1” and “down 2” buttons simultaneously, the factory setting is restored
Note:
Heating mode – Start temperature
Cooling Mode – Startup Temperature> Stop Temperature
You can set 1 heating 1 cooling or 2 cooliong or 2 heating.
Notes: there is no direct voltage output, you must use an additional power source for the load.

Specifications of STC-3008 Temperature Thermostat Controller Dual LED NTC Probe 12/24V 110-220V-Black

Additional information

Weight465 g
